Meanwell HSP-300-5 5V60A 300W LED Sign EMC Power Supply

Meanwell HSP-300-5 5V60A 300W LED Sign EMC Power Supply Features:Universal AC input / Full rangeWithstand 300VAC surge input for 5 secondsBuilt-in active PFC functionLow leakage currentProtections: Short circuit / Overload / Over voltage / Over temperatureCooling by free air convectionLow profile:31mmConformal coatedLED indicator for power onSuitable for high efficiency moving sign applications3 years warrantyMeanwell HSP-300-5 5V60A 300W LED Sign EMC Power Supply Parameter:MODELHSP-300-5OUTPUTDC VOLTAGE5VRATED CURRENT60ACURRENT RANGE0 ~ 60ARATED POWER300WRIPPLE & NOISE (max.) Note.2150mVp-pVOLTAGE ADJ. RANGE4.5~5.5VVOLTAGE TOLERANCE Note.3±2.0%LINE REGULATION Note.4±0.5%LOAD REGULATION Note.5±1.0%SETUP, RISE TIME2000ms, 100ms/230VAC 3000ms, 100ms/115VAC at full loadHOLD UP TIME (Typ.)8ms/230VAC         8ms/115VAC at full loadINPUTVOLTAGE RANGE180 ~ 264VAC     254 ~ 370VDC or 90~135VAC    127~190VDCFREQUENCY RANGE47 ~ 63HzPOWER FACTOR (Typ.)PF≥0.93/230VAC PF ≥0.98/115VAC at full loadEFFICIENCY (Typ.)87� CURRENT (Typ.)4.7A/115VAC        2.35A/230VACINRUSH CURRENT (Typ.)Cold start 30A/115VAC 60A/230VACLEAKAGE CURRENT / 240VACPROTECTIONOVER LOAD105~150% rated output powerProtection type : Hiccup mode, recovers automatically after faultcondition is removed5.7 ~ 7.0VOVER VOLTAGEProtection type : Shut down o/p voltage, re-power on to recoverOVER TEMPERATUREShut down o/p voltage, recovers automatically after fault condition is removedENVIRONMENTWORKING TEMP.-30 ~  70℃(Refer to “Derating Curve”)WORKING HUMIDITY20 ~ 90% RH non-condensingSTORAGE TEMP., HUMIDITY-40 ~  85℃, 10 ~ 95% RHTEMP. COEFFICIENT±0.03%/℃ (0 ~ 60℃)VIBRATION10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axesSAFETY& EMCSAFETY STANDARDSUL60950-1,EN60950-1,CCC GB4943 approvedWITHSTAND VOLTAGEI/P-O/P:3.0KVAC    I/P-FG:2.0KVAC O/P-FG:0.5KVACISOLATION RESISTANCEI/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC/25℃/ 70%RHEMC EMISSIONCompliance to EN55022 (CISPR22),GB9254, Class B, EN61000-3-2,-3,GB17625.1EMC IMMUNITYCompliance to EN61000-4-2,3,4,5,6,8,11; EN55024, light industry level (surge 4KV), criteria AOTHERSMTBF263.2K hrs min.     MIL-HDBK-217F (25℃)DIMENSION210*81*31mm (L*W*H)PACKING0.8kg; 15pcs/ 12.1kg/ 0.7CUFTMore pictures of Meanwell HSP-300-5 5V60A 300W LED Sign EMC Power Supply：Download Specification:Meanwell HSP-300-5 5V60A 300W LED Sign EMC Power Supply Specification
