Indoor Flexible LED Module: 2mm RGB Panel, 256x128mm, 8192 Dots, 600 Nits Indoor

HKXR2M (P2) Indoor Flexible LED Display Module, 2mm Full RGB Pixel LED Display Panel Screen in 256 * 128 mm with 8192 dots, 1/32 Scan, 600 Nits LED Tile for Indoor DisplayIncluded 1 * Data Cable 1 * P2 256*128mm RGB full color LED display moduleItemsHKXR2MTechnical ParametersPixel Configuration1R1G1B Full ColorEncapsulationSMD1515Pixel Density (dots/m2)250000Module Size (mm)256x128x8.6 (Width x Height x Thickness)Moduel Resolution (dots)128×64Scan Mode1/32Standard Dirver IC (Optional)PWMRefresh Rate (Hz)3840Frame Rate (Hz)60Gray Scale (bit)12-13 adjustableSplicing diameter/mm652Curved arc≥158°Data Interface TypeHUB75 (1 in 1 out )Moduel Barcket MaterialsSilicone soft bottom shellModule Weight (Kg/pcs)0.225Cabinet Eveness (mm)≤ 0.5IP Protection GradeIP20Assembly / Maintanance TypeFront & Rear Assembly / MaintenancePhotoelectronic Special FeaturesBrightness (nits)600-800Color Temperature (K)10,000—12,000 AdjustableCoordinateX:0.2500  Y:0.3000  ± 0.01Horizontal / Vertical Veiw AngleX: 150°  /  Y: 120°Contrast Ratio≥5000:1Electrical ParametersModule Input Voltage DC（V）5Moduel Maximum Current DC（A）2.8Module Maximum Power Consumption（w/pcs）14Working Input Voltage AC（V）110—220Peak Power Consumption（w/m2）490Average Power Consumption（w/m2）140Application ParametersTypical Life Span（hrs）100,000Working Temperature（℃）-20—40Storage Temperaure（℃）-20—40Operating temperature range（℃）-20—40 ℃Operating humidity range（RH）20%—75%RH
