TAG-101 Audio Generator MYAMI | Audio Signal Generator Supplier in Bangladesh

TAG-101 Audio Generator একটি high precision signal generator যা electronics laboratory, engineering university এবং circuit testing-এর জন্য ব্যবহৃত হয়। MYAMI brand এর এই generator 10Hz থেকে 1MHz পর্যন্ত frequency range প্রদান করে এবং sine ও square waveform output তৈরি করতে সক্ষম। Specification Details Product Name Audio Generator Model TAG-101 Brand MYAMI Country of Origin China Importer & Supplier RTC Dhaka, Bangladesh Oscillation Frequency ×1 Range: 10Hz – 100Hz ×10 Range: 100Hz – 1KHz ×100 Range: 1KHz – 10KHz ×1K Range: 10KHz – 100KHz ×10K Range: 100KHz – 1MHz Frequency Accuracy ±3% 1Hz Output Impedance 600Ω Output Attenuator 0dB, 10dB, 20dB, 30dB, 40dB, 50dB Sine Wave Output Voltage 5V – 6V Frequency Response 10Hz – 1MHz : ±0.5dB Distortion 400Hz – 20KHz ≤0.1% 100Hz – 100KHz ≤0.3% 50Hz – 200KHz ≤0.5% 20Hz – 500KHz ≤1% 10Hz – 1KHz ≤1.5% Square Wave Output Voltage ≥10Vp-p Up / Down Time 0.5µs Duty Cycle 45:55 Synchronization Range ≤1% Vrms Input Pressure Limit 15V Power Supply AC 220V / 110V ±10%, 50Hz / 60Hz Dimensions 239 × 140 × 200 mm Weight 2.5 Kg Additional SEO Keywords : Audio Generator Bangladesh, Audio Signal Generator Bangladesh, Electronics Laboratory Equipment Bangladesh, Engineering Laboratory Equipment Supplier Bangladesh, Audio Generator ,for Engineering Lab, Signal Generator Supplier Bangladesh, Electronic Test Equipment Bangladesh.
