sa wall and glass mounted brackets

Details The SA Wall and Glass Mounted Brackets by Componance are stainless steel handrail brackets available for wall and glass applications. Modern lines with a balance of strength and graceful delicateness. Complementing square glazing standoffs for glass mounting (1-1/2″ & 2″ lengths) available here. Specifications Wall Mount Dimensions: W 44.5mm (1.8″) x H 117mm (4.6″) x D 74.6mm (2.9″) Minimum 38mm (1.5″) solid backing, wood stud, or concrete required for anchoring Suggested spacing: 1220mm (4Inch-0″) Includes all fasteners except 2 10 flat head wood screws Glass Mount Dimensions: W 44.5mm (1.8″) x H 117mm (4.6″) x D 76.2mm (3″) Requires 19mm (0.75″) diameter hole in glass specify glass thickness when ordering Suggested spacing: 1220mm (4Inch-0″) Includes all fasteners except 2 10 flat head wood screws Materials 304stainless steel Available Finishes Brushed Stainless Steel Powder Coated Black Powder Coated White Product Downloads Wall Mount SA-Wall Product Sheet (PDF) SA-Wall 2D AutoCAD Blocks (DWG) SA-Wall Sketchup Drawing (SKP) SA-Wall Installation Instructions (PDF) Glass Mount SA-Glass Product Sheet (PDF) SA-Glass 2D AutoCAD Blocks (DWG) SA-Glass Sketchup Drawing (SKP) SA-Glass Installation Instructions (PDF)
